Wago - 870-409

Insulated push-in type comb-style jumper bar - 9-way - WAGO (870 X-COM series) - 9-poles (9P) - Rated current 18A - Light Gray color - Dimensions W44mm x D2.5mm - equivalent to 870409

Specifications

• Primary brand: WAGO
• Functions: Insulated push-in type comb-style jumper bar
• Design: 9-way
• Poles: 9-poles (9P)
• Rated current: 18A
• Color: Light Gray
• Dimensions: W44mm x D2.5mm
• eClass code: 27-14-11-40
• Customs Tariff Number: 85366990990
• ETIM code: EC000489
• GTIN code: 4066966272093
• Order code / Manufacturer SKU: 870-409
• Manufacturer product status: Commercialized
• Equivalent to: 870409
• EAN code: 4044918508438
• Compliant with standard(s): RoHS compliant
• Location of origin: Germany
• Level 1 category: Electrical components
• Product title: Insulated push-in type comb-style jumper bar - WAGO (X-COM series)

Commercial data

• Country of origin: DE
• Customs tariff number: 85366990990
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-14-11-40
• eCl@ss 9.0: 27-14-11-40
• ETIM 8.0: EC000489
• ETIM 9.0: EC000489
• GTIN: 4066966272093
• Packaging type: Bag
• PU (SPU): 25 (25) pcs

Electrical data

• Ex information - Rated current (Ex e II): 13.5A
• Ratings per IEC/EN - Rated current: 18A

Environmental Product Compliance

• RoHS Compliance Status: Compliant,No Exemption

Material data

• Color: light gray
• Fire load: 0.049MJ
• Note (material data):
  Information on material specifications can be found here

• Weight: 3.9g

Physical data

• Height: 2.5 mm / 0.098 inches
• Jumper assignment: 1-2-3-4-5-6-7-8-9
• Width: 44 mm / 1.732 inches
