Wago - 859-731

Fixed-type solid-state / static relay (SSR) with red LED - 2-wire connection - WAGO (859 series) - 2-channels / 2-poles / 2-phases (2P) - control voltage 100-120Vdc (110Vdc nom.) - Rated voltage 3Vdc-30Vdc (24Vdc nom.) output - Rated current 3A (continuous) - with CAGE CLAMP connections - DIN-35 rail mounting (6mm width) - equivalent to 859731

Specifications

• Primary brand: WAGO
• Functions: Fixed-type solid-state / static relay (SSR)
• Design: red LED|2-wire connection
• Poles: 2-channels / 2-poles / 2-phases (2P)
• Frequency: 70Hz switching frequency
• Temperature: Processing temperature -25°C...+50°C
• Rated current: 3A (continuous)
• Rated Voltage (DC): 3Vdc-30Vdc (24Vdc nom.) output
• Connection type: CAGE CLAMP connections
• Control Voltage (DC): 100-120Vdc (110Vdc nom.)
• Mounting mode: DIN-35 rail
• Response time: (switching ON) 500μs / 0.0005s|(switching OFF) 6ms / 0.006s
• Dimensions: H91mm x W6mm x D56mm|6mm width
• Material: Polyamide (PA) 66
• Ambient air temperature for operation: -25°C...+70°C
• Ambient air temperature for storage: -40°C...+70°C
• Humidity: 5-95% relative humidity (RH; non-condensing)
• Customs Tariff Number: 85365005000
• ETIM code: EC001504
• GTIN code: 4055143605021
• Order code / Manufacturer SKU: 859-731
• Manufacturer product status: Commercialized
• Equivalent to: 859731
• EAN code: 4055143605021
• Compliant with standard(s): Safety and protection|- Overvoltage category -- II|EN 61000-6-2|EN 61000-6-3|EN 61010-2-201|UL 508|General approvals|- EAC - GZO Almaty Standart - TP TC 004/2011 - certificate EAC CoC 03078|- EAC - GZO Almaty Standart - TP TC 020/2011 - certificate EAC CoC 03081|- UL - Underwriters Laboratories Inc. (ORDINARY LOCATIONS) - UL 508 - certificate E175199 Sec.4|Declarations of conformity and manufacturer's declarations|- EU-Declaration of Conformity - WAGO GmbH & Co. KG|- UK-Declaration of Conformity - WAGO GmbH & Co. KG|RoHS compliant with exemption (7(a) / 7(c)-I)|material group I|V-0 flammability rating
• Location of origin: Germany
• Degree of pollution: 2
• Level 1 category: Automation components
• Level 2 category: Control components
• Level 3 category: Control relays
• Product title: Fixed-type solid-state / static relay (SSR) - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85365005000
• ECCN: NO US CLASSIFICATION
• ETIM 8.0: EC001504
• ETIM 9.0: EC001504
• GTIN: 4055143605021
• Packaging type: Box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 1 pcs

Connection data

• Connection technology: CAGE CLAMP^®
• Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
• Fine-stranded conductor; with insulated ferrule: 0.08 … 1.5 mm² / 28 … 16 AWG
• Fine-stranded conductor; with uninsulated ferrule: 0.2 … 1.5 mm² / 24 … 14 AWG
• Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
• Strip length: 5 … 6 mm / 0.2 … 0.24 inches

Environmental Product Compliance

• CAS-No.: 1303-86-2|1317-36-8|7439-92-1|79-94-7
• REACH Candidate List Substance: 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol|Diboron trioxide|Lead|Lead monoxide
• RoHS Compliance Status: Compliant,With Exemption
• RoHS Exemption: 7(a)|7(c)-I
• SCIP notification number (Austria): 5e21fa6e-4eb4-463c-b3fa-78ec7eebd581
• SCIP notification number (Belgium): bb1fb17a-0c98-4aaa-94b6-800d3096f94b
• SCIP notification number (Bulgaria): fe949cf6-01d5-4087-b60b-f5f657477a5a
• SCIP notification number (Czech Republic): 39d7c6a2-4c0b-4efc-bc08-a0d116cbdea3
• SCIP notification number (Denmark): 37a2b05c-9d2e-4762-9938-55a58a3ef514
• SCIP notification number (Finland): f26cfeeb-9d9d-4aea-a4a0-f6ffe8557ee4
• SCIP notification number (France): 559dc5c8-d81f-4a8b-bb66-bcd1063c5db9
• SCIP notification number (Germany): 042212ee-9d85-44b7-8f97-9e345dbb3977
• SCIP notification number (Hungary): 5c17722c-971a-4f7f-a826-54fbb43917a9
• SCIP notification number (Italy): 3aaffb28-deca-4738-9db7-f85cfa19c532
• SCIP notification number (Netherlands): 7c7deded-e352-46c8-9186-9c63d050fde3
• SCIP notification number (Poland): 4a1270c5-f66f-4ca2-8586-1db58a175c34
• SCIP notification number (Romania): 2c8b78c6-0060-460e-b307-4be8f71cf2d7
• SCIP notification number (Sweden): 3eef45f4-2317-4f44-a218-5c2ce339e2ce

Environmental requirements

• Ambient temperature (operation at U_N): -25 … +70 °C
• Ambient temperature (storage): -40 … +70 °C
• Ambient temperature UL (operation at U_N): -25 … +30 °C
• Operating altitude (max.): 2000m
• Processing temperature: -25 … +50 °C
• Relative humidity: 5 … 95 % (no condensation permissible)
• Temperature range of connection cable: ≥ (T_ambient + 20 K)

Material data

• Color: gray
• Fire load: 0.338MJ
• Flammability class per UL94: V0
• Insulation material (main housing): Polyamide (PA66)
• Material group: I
• Note (material data):
  Information on material specifications can be found here

• Weight: 15.5g

Mechanical data

• Mounting position: horizontal (standing/lying); vertical
• Mounting type: DIN-35 rail

Notes

• Note: Optocouplers and solid state relays are designed for use in signal processing networks that are not supplied directly by the low-voltage power supply network.

Physical data

• Depth from upper-edge of DIN-rail: 56 mm / 2.205 inches
• Height: 91 mm / 3.583 inches
• Width: 6 mm / 0.236 inches

Safety and protection

• Dielectric strength (control/load circuit) (AC, 1 min): 3 kVrms
• Insulation type (between adjacent devices of the same type): Reinforced insulation (safe isolation)
• Insulation type (control/load circuit): Reinforced insulation (safe isolation)
• Overvoltage category: II
• Pollution degree: 2
• Protection type: IP20; in connected state or when using 859-525 end plate
• Rated voltage: 150V
• Type of circuits: Mains circuits

Standards and specifications

• Standards/specifications: EN 61010-2-201|EN 61000-6-2|EN 61000-6-3|UL 508

Technical data

• Control circuit - Input voltage range (high level): 100 … 120 VDC
• Control circuit - Input voltage range (low level): 0 … 60 VDC
• Control circuit - Nominal input current at U_N: 4 mA
• Control circuit - Nominal input voltage U_N: 110 VDC
• Load circuit - Circuit type: 2-wire connection
• Load circuit - Limiting continuous current: 3 A
• Load circuit - Nominal output voltage: 24 VDC
• Load circuit - Output voltage range: 3 … 30 VDC
• Load circuit - Peak output current: 25A
• Load circuit - Switching frequency: ≤ 70 Hz
• Load circuit - Turn-off time: ≤ 6 ms
• Load circuit - Turn-on time: ≤ 500 µs
• Load circuit - Voltage drop: ≤ 0.4 VDC
• Signaling - Status indicator: Red LED
