Fixed-type solid-state / static relay (SSR) with red LED - 2-wire connection - for railways applications - WAGO (859 series) - single-pole / single-phase / 1-pole (1P) - control voltage 77-137.5Vdc (110Vdc nom.) - Rated voltage 12Vdc-30Vdc (24Vdc nom.) output - Rated current 0.05A (continuous) - with CAGE CLAMP connections - DIN-35 rail mounting (6mm width) - equivalent to 859722

Specifications

• Primary brand: WAGO
• Functions: Fixed-type solid-state / static relay (SSR)
• Design: red LED|2-wire connection|for railways applications
• Poles: single-pole / single-phase / 1-pole (1P)
• Frequency: 1.5kHz switching frequency
• Temperature: Processing temperature -25°C...+50°C
• Rated current: 0.05A (continuous)
• Rated Voltage (DC): 12Vdc-30Vdc (24Vdc nom.) output
• Connection type: CAGE CLAMP connections
• Control Voltage (DC): 77-137.5Vdc (110Vdc nom.)
• Mounting mode: DIN-35 rail
• Response time: (switching ON) 20μs / 0.00002s|(switching OFF) 120μs / 0.00012s
• Dimensions: H91mm x W6mm x D56mm|6mm width
• Material: Polyamide (PA) 66
• Ambient air temperature for operation: -40°C...+70°C
• Ambient air temperature for storage: -40°C...+70°C
• Humidity: 5-95% relative humidity (RH; non-condensing)
• ETIM code: EC001504
• GTIN code: 4055143604864
• Customs Tariff Number: 85365005000
• eClass code: 27-26-15-03
• Order code / Manufacturer SKU: 859-722
• Manufacturer product status: Commercialized
• Equivalent to: 859722
• EAN code: 4055144129892
• Compliant with standard(s): Safety and protection|- Overvoltage category -- II|EN 50121-3-2|EN 61000-6-2|EN 61000-6-3|EN 61010-2-201|General approvals|- EAC - GZO Almaty Standart - TP TC 004/2011 - certificate EAC CoC 03078|- EAC - GZO Almaty Standart - TP TC 020/2011 - certificate EAC CoC 03081|Declarations of conformity and manufacturer's declarations|- EU-Declaration of Conformity - WAGO GmbH & Co. KG|RoHS compliant with exemption (7(a))|material group I|V-0 flammability rating
• Location of origin: Germany
• Degree of pollution: 2
• Application type: Railways applications
• Level 1 category: Automation components
• Level 2 category: Control components
• Level 3 category: Control relays
• Product title: Fixed-type solid-state / static relay (SSR) - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85365005000
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-26-15-03
• eCl@ss 9.0: 27-26-15-03
• ETIM 8.0: EC001504
• ETIM 9.0: EC001504
• GTIN: 4055143604864
• Packaging type: Box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 1 pcs

Connection data

• Connection technology: CAGE CLAMP^®
• Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
• Fine-stranded conductor; with insulated ferrule: 0.08 … 1.5 mm² / 28 … 16 AWG
• Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
• Strip length: 5 … 6 mm / 0.2 … 0.24 inches

Environmental Product Compliance

• CAS-No.: 7439-92-1|79-94-7
• REACH Candidate List Substance: 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol|Lead
• RoHS Compliance Status: Compliant,With Exemption
• RoHS Exemption: 7(a)
• SCIP notification number (Austria): dfe1a7d2-46c3-4d04-bf7a-4858403092f5
• SCIP notification number (Belgium): f43dc37c-bdb5-4588-b72f-4306f91941b4
• SCIP notification number (Bulgaria): f19c7c25-c6e0-4ab5-aae5-db993d266f19
• SCIP notification number (Czech Republic): da301c04-9d3d-4478-8d7a-e3f9c5c6bc85
• SCIP notification number (Denmark): 34f0dda5-2fd0-4fc4-b12c-d65b9b7e51c7
• SCIP notification number (Finland): 64740d19-2f2a-4f26-91b3-9280c978c794
• SCIP notification number (France): 91974923-8418-48b0-b0a8-1d0533551dc3
• SCIP notification number (Germany): ace42152-917e-487e-8ff2-72adb1344ae7
• SCIP notification number (Hungary): c1343e58-9756-4347-9198-0b6419497f9b
• SCIP notification number (Italy): f44d140b-ae40-49bc-9be4-f06151455832
• SCIP notification number (Netherlands): 55c35486-71b3-4589-ba95-f658d975343b
• SCIP notification number (Poland): 56e2c9b1-d3e7-46ea-b859-a513abd99dc1
• SCIP notification number (Romania): ed33b97c-9e70-4800-9cd2-06e7f46aecf7
• SCIP notification number (Sweden): de616fd9-5afb-4b92-ada0-a580fb1d138f

Environmental requirements

• Ambient temperature (operation at U_N): -40 … +70 °C
• Ambient temperature (storage): -40 … +70 °C
• Operating altitude (max.): 2000m
• Processing temperature: -25 … +50 °C
• Relative humidity: 5 … 95 % (no condensation permissible)
• Temperature range of connection cable: ≥ (T_ambient + 20 K)

Material data

• Color: gray
• Fire load: 0.338MJ
• Flammability class per UL94: V0
• Insulation material (main housing): Polyamide (PA66)
• Material group: I
• Note (material data):
  Information on material specifications can be found here

• Weight: 18.3g

Mechanical data

• Mounting position: horizontal (standing/lying); vertical
• Mounting type: DIN-35 rail

Notes

• Note: Optocouplers and solid state relays are designed for use in signal processing networks that are not supplied directly by the low-voltage power supply network.

Physical data

• Depth from upper-edge of DIN-rail: 56 mm / 2.205 inches
• Height: 91 mm / 3.583 inches
• Width: 6 mm / 0.236 inches

Safety and protection

• Dielectric strength (control/load circuit) (AC, 1 min): 3 kVrms
• Insulation type (adjacent devices): Reinforced insulation (safe isolation)
• Insulation type (between adjacent devices of the same type): Reinforced insulation (safe isolation)
• Insulation type (control/load circuit): Reinforced insulation (safe isolation)
• Insulation type (to adjacent devices of different types): Basic insulation
• Overvoltage category: II
• Pollution degree: 2
• Protection type: IP20; in connected state or when using 859-525 end plate
• Rated voltage: 300V
• Type of circuits: Mains circuits

Standards and specifications

• Standards/specifications: EN 61010-2-201|EN 61000-6-2|EN 61000-6-3|EN 50121-3-2

Technical data

• Control circuit - Input voltage range (high level): 77 … 137.5 VDC
• Control circuit - Input voltage range (low level): 0 … 20 VDC
• Control circuit - Nominal input current at U_N: 3 mA
• Control circuit - Nominal input voltage U_N: 110 VDC
• Load circuit - Circuit type: 2-wire connection
• Load circuit - Leakage current at rated voltage: ≤ 25 µA
• Load circuit - Limiting continuous current: 0.05 A
• Load circuit - Nominal output voltage: 24 VDC
• Load circuit - Output voltage range: 12 … 30 VDC
• Load circuit - Switching frequency: ≤ 1.5 kHz
• Load circuit - Turn-off time: ≤ 120 µs
• Load circuit - Turn-on time: ≤ 20 µs
• Load circuit - Voltage drop: ≤ 2 VDC
• Signaling - Status indicator: Red LED
