Wago - 789-508

Fixed-type relay module with red LED - WAGO (789 series) - single-pole / 1-pole (1P) - control voltage 195.5-253Vac (230Vac nom.; 0.85...1.1 x Uc) - 1C/O / SPDT (Single Pole Double Throw) contact - Electromechanical design - Rated current 12A (continuous) - with CAGE CLAMP connections - DIN-35 rail mounting (17.5mm width) - IP20 - material Silver-Nickel (AgNi 90/10) contacts - equivalent to 789508

Specifications

• Primary brand: WAGO
• Functions: Fixed-type relay module
• Design: red LED|Electromechanical design|12V / 10mA recommended minimum switching load
• Poles: single-pole / 1-pole (1P)
• Temperature: Processing temperature -25°C...+50°C
• Rated current: 12A (continuous)|30A (4s) AC inrush maximum current
• Rated operating voltage (Ue): 250V
• Rated voltage (AC): 250Vac max. (switching voltage)
• Rated impulse voltage (Uimp): 4kV
• Connection type: CAGE CLAMP connections
• Control Voltage (AC): 195.5-253Vac (230Vac nom.; 0.85...1.1 x Uc)
• Mounting mode: DIN-35 rail
• Response time: (OFF=>ON / contacts closing) 15ms / 0.015s|(ON=>OFF / contacts opening) 15ms / 0.015s
• Contacts type: 1C/O / SPDT (Single Pole Double Throw) contact
• Dimensions: H90mm x W17.5mm x D55mm|17.5mm width
• Material: Silver-Nickel (AgNi 90/10) contacts
• Ambient air temperature for operation: -25°C...+40°C
• Ambient air temperature for storage: -40°C...+85°C
• Mechanical durability (at no load): 10 000 000operations
• eClass code: 27-14-23-09
• ETIM code: EC001437
• GTIN code: 4017332819398
• Customs Tariff Number: 85364900990
• Order code / Manufacturer SKU: 789-508
• Manufacturer product status: Commercialized
• Equivalent to: 789508
• EAN code: 4017332819398
• Compliant with standard(s): EN 60664-1|General approvals|- EAC - GZO Almaty Standart - TP TC 004/2011 - certificate EAC CoC 03084|RoHS compliant with exemption (7(a))
• Location of origin: Germany
• Degree of pollution: 2
• Level 1 category: Automation components
• Level 2 category: Control components
• Level 3 category: Control relays
• Product title: Fixed-type relay module - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85364900990
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-14-23-09
• eCl@ss 9.0: 27-14-23-09
• ETIM 8.0: EC001437
• ETIM 9.0: EC001437
• GTIN: 4017332819398
• Packaging type: box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 10 (1) pcs

Connection data

• Connection technology: CAGE CLAMP^®
• Fine-stranded conductor: 0.2 … 2.5 mm² / 24 … 14 AWG
• Solid conductor: 0.2 … 2.5 mm² / 24 … 14 AWG
• Strip length: 9 … 10 mm / 0.35 … 0.39 inches

Environmental Product Compliance

• CAS-No.: 7439-92-1|79-94-7
• REACH Candidate List Substance: 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol|Lead
• RoHS Compliance Status: Compliant,With Exemption
• RoHS Exemption: 7(a)
• SCIP notification number (Austria): c1fb0bae-9d6d-4d3d-9bdd-502de3047fd6
• SCIP notification number (Belgium): 4927c211-6930-4af5-b1b7-701d96febcd3
• SCIP notification number (Bulgaria): a53011e6-a6ed-4b17-8963-1a14678b3de2
• SCIP notification number (Czech Republic): 4e8324a2-637f-4cca-9aee-4a6ca6fca09f
• SCIP notification number (Denmark): 0f9c3f2d-2299-49b9-bd42-ecf027d927eb
• SCIP notification number (Finland): 6fb1e048-5657-44d0-84cd-fd1595bc717a
• SCIP notification number (France): c83059ee-da77-4956-8264-e341334a6c5b
• SCIP notification number (Germany): a0045889-65d8-4ce8-92b4-bfb8716cfaa0
• SCIP notification number (Hungary): 3e45979d-be91-470e-acb3-0b4b120d91fd
• SCIP notification number (Italy): 39f663be-19a4-4281-9859-9acb90eb8a28
• SCIP notification number (Netherlands): 8e10941f-bb71-4e09-b008-ac98f3d39828
• SCIP notification number (Poland): bf868741-072e-4ec1-9b1b-c9280d6fb0c8
• SCIP notification number (Romania): 4fb61784-5a02-4f7f-8b63-fff6fa7f5e4b
• SCIP notification number (Sweden): 23f1dfd6-da79-41f5-8b51-934953dc475f

Environmental requirements

• Ambient temperature (operation at U_N): -25 … +40 °C
• Ambient temperature (storage): -40 … +85 °C
• Processing temperature: -25 … +50 °C

Material data

• Color: gray
• Fire load: 0.764MJ
• Note (material data):
  Information on material specifications can be found here

• Weight: 49.2g

Mechanical data

• Housing design: DIN-rail-mount enclosure
• Mounting type: DIN-35 rail

Notes

• Note: To protect the relay coils and contacts, inductive loads must be dampened with an effective protection circuit.

Physical data

• Depth from upper-edge of DIN-rail: 55 mm / 2.165 inches
• Height: 90 mm / 3.543 inches
• Width: 17.5 mm / 0.689 inches

Safety and protection

• Dielectric strength (control/load circuit) (AC, 1 min): 5 kVrms
• Dielectric strength (open contact) (AC, 1 min): 1 kVrms
• Pollution degree: 2
• Protection type: IP20
• Rated impulse withstand voltage: 4kV
• Rated voltage: 250V

Standards and specifications

• Standards/specifications: EN 60664-1

Technical data

• Control circuit - Input voltage range: -15 … +10 %
• Control circuit - Nominal input current at U_N: 5 mA
• Control circuit - Nominal input voltage U_N: 230 VAC
• Load circuit - Bounce time (typ.): 3ms
• Load circuit - Contact material (relay): AgNi 90/10
• Load circuit - Drop-out time (typ.): 15ms
• Load circuit - Inrush current (resistive) max.: (AC) 30 A / 4 s
• Load circuit - Limiting continuous current: 12 A
• Load circuit - Mechanical life: 10 x 10⁶ switching operations
• Load circuit - Number of changeover/switchover contacts: 1
• Load circuit - Pull-in time (typ.): 15ms
• Load circuit - Recommended minimum load: 12 V / 10 mA
• Load circuit - Switching power (resistive) max.: AC 3000 VA; DC (see load limit curve)
• Load circuit - Switching Voltage, Max.: 250 VAC
• Signaling - Status indicator: Red
