Replacement plug-in basic relay - WAGO (788 series) - 2-poles (2P) - control voltage 24Vdc - 2C/O / DPDT (Double Pole Double Throw) contact - Electromechanical design - Rated current 6A (continuous) / 3A (250Vac; AC-15) / 3A (24Vdc; DC-13) - with Push-in connections - Plug-in mounting - IP20 - material Silver-Nickel (AgNi) contacts - equivalent to 788902

Specifications

• Primary brand: WAGO
• Functions: Replacement plug-in basic relay
• Design: Electromechanical design|5V / 10mA recommended minimum switching load
• Poles: 2-poles (2P)
• Rated current: 6A (continuous)|3A (250Vac; AC-15)|3A (24Vdc; DC-13)|14A (4s) AC inrush maximum current
• Rated voltage (AC): 250Vac max. (switching voltage)
• Connection type: Push-in connections
• Control Voltage (DC): 24Vdc
• Mounting mode: Plug-in
• Response time: (OFF=>ON / contacts closing) 10ms / 0.010s|(ON=>OFF / contacts opening) 4ms / 0.004s
• Contacts type: 2C/O / DPDT (Double Pole Double Throw) contact
• Dimensions: H15.7mm x W12.7mm x D29mm
• Material: Silver-Nickel (AgNi) contacts
• Ambient air temperature for operation: -40°C...+85°C
• Ambient air temperature for storage: -40°C...+85°C
• Electrical durability (with load): 100 000operations
• Mechanical durability (at no load): 10 000 000operations
• ETIM code: EC001437
• GTIN code: 4050821508144
• Customs Tariff Number: 85364900990
• Order code / Manufacturer SKU: 788-902
• Manufacturer product status: Commercialized
• Equivalent to: 788902
• EAN code: 4050821508144
• Compliant with standard(s): EN 61810-1|EN 61810-3|General approvals|- EAC - GZO Almaty Standart - TP TC 004/2011 - certificate EAC CoC 03084|RoHS compliant
• Location of origin: Germany
• Level 1 category: Automation components
• Level 2 category: Control components
• Level 3 category: Control relays
• Product title: Replacement plug-in basic relay - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85364900990
• ECCN: NO US CLASSIFICATION
• ETIM 8.0: EC001437
• ETIM 9.0: EC001437
• GTIN: 4050821508144
• Packaging type: box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 20 pcs

Environmental Product Compliance

• RoHS Compliance Status: Compliant,No Exemption

Environmental requirements

• Ambient temperature (operation at U_N): -40 … +85 °C
• Ambient temperature (storage): -40 … +85 °C

Material data

• Fire load: 0.266MJ
• Note (material data):
  Information on material specifications can be found here

• Weight: 17.4g

Mechanical data

• Mounting type: Pluggable module

Physical data

• Depth: 29 mm / 1.142 inches
• Height from the surface: 15.7 mm / 0.618 inches
• Width: 12.7 mm / 0.5 inches

Safety and protection

• Dielectric strength (control/load circuit) (AC, 1 min): 4 kVrms
• Dielectric strength (load/load circuit) (AC, 1 min): 3 kVrms
• Dielectric strength (open contact) (AC, 1 min): 1.5 kVrms
• Protection type: IP20

Standards and specifications

• Standards/specifications: EN 61810-1|EN 61810-3

Technical data

• Control circuit - Nominal input voltage U_N: 24 VDC
• Load circuit - Contact material (relay): AgNi
• Load circuit - Drop-out time (typ.): 4ms
• Load circuit - Electrical life (NO; resistive load; 23 °C): 100 x 10³ switching operations
• Load circuit - Inrush current (resistive) max.: (AC) 14 A / 4 s
• Load circuit - Limiting continuous current: 6 A
• Load circuit - Mechanical life: 10 x 10⁶ switching operations
• Load circuit - Number of changeover/switchover contacts: 2
• Load circuit - Pull-in time (typ.): 10ms
• Load circuit - Recommended minimum load: 5 V / 10 mA
• Load circuit - Switching capacity: AC-15: 3 A / 250 VAC; DC-13: 3 A / 24 VDC
• Load circuit - Switching frequency with/without load (max.): 6 min^-1 / 300 min^-1
• Load circuit - Switching power (resistive) max.: AC 1500 VA; DC (see load limit curve)
• Load circuit - Switching Voltage, Max.: 250 VAC
