Wago - 788-121

Operation status indicator with red LED - WAGO (788 series) - control voltage 48Vdc - Plug-in mounting - IP20 - equivalent to 788121

Specifications

• Primary brand: WAGO
• Functions: Operation status indicator
• Design: red LED
• Control Voltage (DC): 48Vdc
• Mounting mode: Plug-in
• ETIM code: EC002586
• GTIN code: 4045454550349
• Customs Tariff Number: 85318070000
• eClass code: 27-37-16-92
• Order code / Manufacturer SKU: 788-121
• Manufacturer product status: Commercialized
• Equivalent to: 788121
• EAN code: 4045454550349
• Compliant with standard(s): RoHS compliant with exemption (7(a))
• Location of origin: Germany
• Level 1 category: Automation components
• Product title: Operation status indicator - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85318070000
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-37-16-92
• eCl@ss 9.0: 27-37-16-92
• ETIM 8.0: EC002586
• ETIM 9.0: EC002586
• GTIN: 4045454550349
• Packaging type: box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 50 (25) pcs

Environmental Product Compliance

• CAS-No.: 7439-92-1|79-94-7
• REACH Candidate List Substance: 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol|Lead
• RoHS Compliance Status: Compliant,With Exemption
• RoHS Exemption: 7(a)
• SCIP notification number (Bulgaria): b37affb3-7a63-4c08-b562-9c2aa4b1e704
• SCIP notification number (Czech Republic): e6884efa-4b07-4509-b20b-c1ccd6476458

Material data

• Fire load: 0.027MJ
• Note (material data):
  Information on material specifications can be found here

• Weight: 1.7g

Mechanical data

• Mounting type: Pluggable module

Notes

• Note: Only required when using relays without integrated status indicator!

Safety and protection

• Protection type: IP20

Technical data

• Operating data - Current consumption at U_N: 1.9 mA
• Operating data - Nominal operating voltage: 48 VDC
• Operating data - Operating voltage: 48 … 60 VDC
• Signaling - Status indicator: Red LED
