Wago - 788-123

Operation status indicator with red LED - WAGO (788 series) - control voltage 24Vac - Plug-in mounting - IP20 - equivalent to 788123

Specifications

• Primary brand: WAGO
• Functions: Operation status indicator
• Design: red LED
• Control Voltage (AC): 24Vac
• Mounting mode: Plug-in
• Customs Tariff Number: 85318070000
• ETIM code: EC002586
• eClass code: 27-37-16-92
• GTIN code: 4045454424077
• Order code / Manufacturer SKU: 788-123
• Manufacturer product status: Commercialized
• Equivalent to: 788123
• EAN code: 4045454424077
• Compliant with standard(s): RoHS compliant
• Location of origin: Germany
• Level 1 category: Automation components
• Product title: Operation status indicator - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85318070000
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-37-16-92
• eCl@ss 9.0: 27-37-16-92
• ETIM 8.0: EC002586
• ETIM 9.0: EC002586
• GTIN: 4045454424077
• Packaging type: box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 50 (25) pcs

Environmental Product Compliance

• RoHS Compliance Status: Compliant,No Exemption

Material data

• Fire load: 0.033MJ
• Note (material data):
  Information on material specifications can be found here

• Weight: 1.6g

Mechanical data

• Mounting type: Pluggable module

Notes

• Note: Only required when using relays without integrated status indicator!

Safety and protection

• Protection type: IP20

Technical data

• Control circuit - Nominal input current at U_N: 0
• Operating data - Current consumption at U_N: 2.1 mA
• Operating data - Nominal operating voltage: 24 VAC
• Operating data - Operating voltage: 12 … 24 VAC
• Signaling - Status indicator: Red LED
