Wago - 289-549

Interface module - in mounting carrier - WAGO (289 series) - 50-poles (50P) - with 50-pin D-sub male connector (system; vertical connection) + 3-row spring CAGE CLAMP 50-pin for 0.08...2.5mm2 cables (field) - Rated current 2A - DIN-35 rail mounting (94mm width) - rated for -20°C...+50°C ambient - equivalent to 289549

Specifications

• Primary brand: WAGO
• Functions: Interface module
• Design: in mounting carrier
• Poles: 50-poles (50P)
• Rated current: 2A
• Rated Voltage (DC): 125Vdc
• Rated voltage (AC): 125Vac
• Connection type: 50-pin D-sub male connector (system; vertical connection)|3-row spring CAGE CLAMP 50-pin for 0.08...2.5mm2 cables (field)
• Mounting mode: DIN-35 rail
• Dimensions: H85mm x W94mm x D34mm
• Net Width (mm): 94mm
• Ambient air temperature for operation: -20°C...+50°C
• Ambient air temperature for storage: -40°C...+70°C
• Humidity: ≤85% relative humidity (RH; non-condensing)
• GTIN code: 4045454322779
• ETIM code: EC002780
• Customs Tariff Number: 85366990990
• eClass code: 27-14-11-52
• Order code / Manufacturer SKU: 289-549
• Manufacturer product status: Commercialized
• Equivalent to: 289549
• EAN code: 4017332457439
• Compliant with standard(s): EN 61010-2-201|General approvals|- EAC - GZO Almaty Standart - TP TC 004/2011 - certificate EAC CoC 03084|- UL - Underwriters Laboratories Inc. (ORDINARY LOCATIONS) - UL 508 - certificate E175199 Vol.2 Sec.1|Declarations of conformity and manufacturer's declarations|- EU-Declaration of Conformity - WAGO GmbH & Co. KG|- UK-Declaration of Conformity - WAGO GmbH & Co. KG|RoHS compliant with exemption (6(c))
• Location of origin: Germany
• Degree of pollution: 2
• Level 1 category: Automation components
• Product title: Interface module - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85366990990
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-14-11-52
• eCl@ss 9.0: 27-14-11-52
• ETIM 8.0: EC002780
• ETIM 9.0: EC002780
• GTIN: 4045454322779
• Packaging type: box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 4 (1) pcs

Connection data

• Connection 1 - Connection type 1: System
• Connection 1 - Mating direction: vertical
• Connection 1 - Note (conductor cross-section): 12 AWG: THHN, THWN
• Connection 1 - Pluggable connector: D-subminiature male connector
• Connection 1 - Pole number 1: 50
• Connection 2 - Connection technology: CAGE CLAMP^®
• Connection 2 - Connection type: Field
• Connection 2 - Design 2: PCB terminal blocks (triple-row)
• Connection 2 - Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Connection 2 - Pole number 2: 50
• Connection 2 - Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Connection 2 - Strip length: 5 … 6 mm / 0.2 … 0.24 inches
• Connection 2 - WAGO connector 2: WAGO 236 Series
• Performance level: 2 / 200 mating cycles
• Strain relief: UNC 4-40 stud bolt

Electrical data

• Contact resistance (max.): 30 mΩ
• Nominal current: 2A
• Operating voltage: ≤ 125 VAC/VDC

Environmental Product Compliance

• CAS-No.: 7439-92-1
• REACH Candidate List Substance: Lead
• RoHS Compliance Status: Compliant,With Exemption
• RoHS Exemption: 6(c)
• SCIP notification number (Austria): fce59caa-8605-437a-bb4e-b7b2984f08ea
• SCIP notification number (Belgium): ce097219-59e2-46c5-a0fe-1e6db5626ab2
• SCIP notification number (Bulgaria): 9a7b3033-cf81-4382-97bb-0376b37e1fb9
• SCIP notification number (Czech Republic): dc1eddd7-0b1f-4b64-9d34-f620dd0cf606
• SCIP notification number (Denmark): a97d6c4c-7fb5-42f0-8e69-0f9ab9764430
• SCIP notification number (Finland): 0cfa19da-d0bb-47d3-afd9-a6db89a5fada
• SCIP notification number (France): e21335a4-783b-4b97-a5b6-39e33c295401
• SCIP notification number (Germany): 6326bb9f-73f8-4d65-9ba5-4ae622e164bb
• SCIP notification number (Hungary): 34c6725a-46c5-4332-8652-90742fc37fb5
• SCIP notification number (Italy): 51e0154d-8f1e-41c2-8050-97e3d6f33dc3
• SCIP notification number (Netherlands): 1918f7fe-6245-4942-bd17-551945470aa5
• SCIP notification number (Poland): 2cf482d2-038b-4e47-81d8-ef7aba2f4924
• SCIP notification number (Romania): 805329a6-9362-4de8-a83f-f3f29d741763
• SCIP notification number (Sweden): 0fa78354-eab2-4667-a49b-1ddefcbcf444

Environmental requirements

• Ambient temperature (operation): -20 … +50 °C
• Ambient temperature (storage): -40 … +70 °C
• Relative humidity: ≤ 85 % (non-condensing)

Material data

• Contact material (connector): Au over Ni
• Fire load: 1.318MJ
• Weight: 123g

Mechanical data

• Housing design: Mounting carrier
• Mounting type: DIN-35 rail

Physical data

• Depth from upper-edge of DIN-rail: 34 mm / 1.339 inches
• Height: 85 mm / 3.346 inches
• Width: 94 mm / 3.701 inches

Safety and protection

• Dielectric strength (channel/channel) (AC, 1 min.): 0.75kV_rms
• Insulation type: Functional insulation
• Pollution degree: 2
• Protection type: IP00
• Rated voltage: 125V

Standards and specifications

• Standards/specifications: EN 61010-2-201
