Wago - 289-449

Interface module - stand-alone PCB with mounting feet - WAGO (289 series) - 50-poles (50P) - with 50-pin D-sub male connector (system; vertical connection) + 2-row spring CAGE CLAMP 50-pin for 0.08...2.5mm2 cables (field) - Rated current 1A - DIN-35 rail mounting (157mm width) - rated for -20°C...+50°C ambient - equivalent to 289449

Specifications

• Primary brand: WAGO
• Functions: Interface module
• Design: stand-alone PCB with mounting feet
• Poles: 50-poles (50P)
• Rated current: 1A
• Rated Voltage (DC): 50Vdc
• Rated voltage (AC): 30Vac
• Connection type: 50-pin D-sub male connector (system; vertical connection)|2-row spring CAGE CLAMP 50-pin for 0.08...2.5mm2 cables (field)
• Mounting mode: DIN-35 rail
• Dimensions: H63.5mm x W157mm x D19mm
• Net Width (mm): 157mm
• Ambient air temperature for operation: -20°C...+50°C
• Ambient air temperature for storage: -40°C...+70°C
• Humidity: ≤85% relative humidity (RH; non-condensing)
• ETIM code: EC002780
• GTIN code: 4045454599423
• Customs Tariff Number: 85366990990
• eClass code: 27-14-11-52
• Order code / Manufacturer SKU: 289-449
• Manufacturer product status: Commercialized
• Equivalent to: 289449
• EAN code: 4045454599423
• Compliant with standard(s): EN 61010-2-201|RoHS compliant with exemption (6(c))
• Location of origin: Germany
• Degree of pollution: 2
• Level 1 category: Automation components
• Product title: Interface module - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85366990990
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-14-11-52
• eCl@ss 9.0: 27-14-11-52
• ETIM 8.0: EC002780
• ETIM 9.0: EC002780
• GTIN: 4045454599423
• Packaging type: box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 5 (1) pcs

Connection data

• Connection 1 - Connection type 1: System
• Connection 1 - Mating direction: vertical
• Connection 1 - Note (conductor cross-section): 12 AWG: THHN, THWN
• Connection 1 - Pluggable connector: D-subminiature male connector
• Connection 1 - Pole number 1: 50
• Connection 2 - Connection technology: CAGE CLAMP^®
• Connection 2 - Connection type: Field
• Connection 2 - Design 2: PCB terminal blocks (double-row)
• Connection 2 - Fine-stranded conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Connection 2 - Pole number 2: 50
• Connection 2 - Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
• Connection 2 - Strip length: 5 … 6 mm / 0.2 … 0.24 inches
• Connection 2 - WAGO connector 2: WAGO 236 Series
• Performance level: 2 / 200 mating cycles
• Strain relief: UNC 4-40 stud bolt

Electrical data

• Contact resistance (max.): 30 mΩ
• Nominal current: 1A
• Operating voltage: ≤ 30 VAC; ≤ 50 VDC

Environmental Product Compliance

• CAS-No.: 7439-92-1
• REACH Candidate List Substance: Lead
• RoHS Compliance Status: Compliant,With Exemption
• RoHS Exemption: 6(c)
• SCIP notification number (Austria): f37bd52d-cd1e-4a17-8b6f-4b4aab35e041
• SCIP notification number (Belgium): 8f5f0157-2460-42b1-8f0e-e973920c5ac9
• SCIP notification number (Bulgaria): a1fe57e8-c7e2-4083-ad37-f47ff4a9b3d0
• SCIP notification number (Czech Republic): 3115decb-3499-4b66-a6c3-d2f3c8ad1a7d
• SCIP notification number (Denmark): 3d5644c9-b42c-41b9-b0c8-bad9387248b9
• SCIP notification number (Finland): 02548901-7b45-497a-accb-3a0379fbeba7
• SCIP notification number (France): 0b73c2fc-5523-44c2-8420-28a35cc9775b
• SCIP notification number (Germany): 1564835a-eec6-4b59-adf1-f87a59435c4a
• SCIP notification number (Hungary): 07e198eb-8d32-4ba2-b773-df9dffa3cd08
• SCIP notification number (Italy): fb299edc-3755-44b5-8273-50a52b8b570f
• SCIP notification number (Netherlands): c5fc6a9b-d5ea-447b-a257-26191caee825
• SCIP notification number (Poland): 50d0a6f1-89ad-4ce5-bc92-c2911bd5eada
• SCIP notification number (Romania): c4d4ffbd-ec01-4af8-a497-6d5498258bc7
• SCIP notification number (Sweden): e806ae4d-101d-44aa-9e74-645a0094d4fc

Environmental requirements

• Ambient temperature (operation): -20 … +50 °C
• Ambient temperature (storage): -40 … +70 °C
• Relative humidity: ≤ 85 % (non-condensing)

Material data

• Contact material (connector): Au over Ni
• Fire load: 0.084MJ
• Weight: 98.7g

Mechanical data

• Housing design: PCB with mounting feet
• Mounting type: DIN-35 rail

Physical data

• Depth from upper-edge of DIN-rail: 19 mm / 0.748 inches
• Height: 63.5 mm / 2.5 inches
• Width: 157 mm / 6.181 inches

Safety and protection

• Insulation type: Basic insulation
• Pollution degree: 2
• Protection type: IP00
• Rated impulse withstand voltage: 0.8kV
• Rated voltage: 50V

Standards and specifications

• Standards/specifications: EN 61010-2-201
