Wago - 288-600

Track section - 1m long - size 1 - WAGO (288 series) - Gray color - DIN-35 rail mounting - Dimensions H71.2mm x W1000mm - equivalent to 288600

Specifications

• Primary brand: WAGO
• Functions: Track section - 1m long
• Design: size 1
• Color: Gray
• Mounting mode: DIN-35 rail
• Dimensions: H71.2mm x W1000mm
• ETIM code: EC001031
• Customs Tariff Number: 39169010900
• GTIN code: 4017332639484
• eClass code: 27-18-27-02
• Order code / Manufacturer SKU: 288-600
• Manufacturer product status: Commercialized
• Equivalent to: 288600
• EAN code: 4017332639484
• Compliant with standard(s): RoHS compliant
• Location of origin: Germany
• Level 1 category: Automation components
• Product title: Track section - 1m long - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 39169010900
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-18-27-02
• eCl@ss 9.0: 27-18-27-02
• ETIM 8.0: EC001031
• ETIM 9.0: EC001031
• GTIN: 4017332639484
• Packaging type: box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 1 (1) pcs

Environmental Product Compliance

• RoHS Compliance Status: Compliant,No Exemption

Material data

• Color: gray
• Weight: 248g

Mechanical data

• Mounting type: DIN-35 rail

Notes

• Note: Length calculation for a complete mounting carrier:
  · PCB length: L1
  · Base length: L2 = L1 - 11 mm
  · Mounting carrier length: L3 = L1 + 2 mm
  · Lateral cover, size 1, 6.35 mm thick
  · Free space between base and PCB (when using upper PCB groove): 5 mm
  ·
  PCB tolerances: 1.5 mm ± 0.2 mm (thickness), ± 0.2 mm (length/width), −0.1/+0.3 for milling contours

Physical data

• Height: 71.2 mm / 2.803 inches
• Width: 1000 mm / 39.37 inches
