Wago - 286-508

Replacement plug-in relay with red LED - WAGO (286 series) - single-pole / 1-pole (1P) - control voltage 207-253Vac (230Vac nom.; 0.9...1.1 x Uc) - 1C/O / SPDT (Single Pole Double Throw) contact - Electromechanical design - Rated current 7A (continuous) - with plug-in connections - Plug-in mounting - IP20 - material Silver-Nickel (AgNi 0.15) contacts - equivalent to 286508

Specifications

• Primary brand: WAGO
• Functions: Replacement plug-in relay
• Design: red LED|Electromechanical design
• Poles: single-pole / 1-pole (1P)
• Temperature: Processing temperature -25°C...+50°C
• Rated current: 7A (continuous)
• Rated operating voltage (Ue): 300V
• Rated voltage (AC): 250Vac max. (switching voltage)
• Rated impulse voltage (Uimp): 4kV
• Connection type: plug-in connections
• Control Voltage (AC): 207-253Vac (230Vac nom.; 0.9...1.1 x Uc)
• Mounting mode: Plug-in
• Response time: (OFF=>ON / contacts closing) 8ms / 0.008s|(ON=>OFF / contacts opening) 6ms / 0.006s
• Contacts type: 1C/O / SPDT (Single Pole Double Throw) contact
• Dimensions: H82.5mm x W15mm x D52mm
• Material: Silver-Nickel (AgNi 0.15) contacts
• Ambient air temperature for operation: -25°C...+40°C
• Ambient air temperature for storage: -25°C...+70°C
• Humidity: 5-75% relative humidity (RH; non-condensing)
• Electrical durability (with load): 100 000operations
• Mechanical durability (at no load): 30 000 000operations
• GTIN code: 4045454560058
• Customs Tariff Number: 85364900990
• eClass code: 27-37-16-01
• ETIM code: EC001437
• Order code / Manufacturer SKU: 286-508
• Manufacturer product status: Commercialized
• Equivalent to: 286508
• EAN code: 4045454560058
• Compliant with standard(s): Safety and protection|- Overvoltage category -- II|EN 61010-2-201|General approvals|- EAC - GZO Almaty Standart - TP TC 004/2011 - certificate EAC CoC 03078|Declarations of conformity and manufacturer's declarations|- EU-Declaration of Conformity - WAGO GmbH & Co. KG|RoHS compliant
• Location of origin: Germany
• Degree of pollution: 2
• Level 1 category: Automation components
• Level 2 category: Control components
• Level 3 category: Control relays
• Product title: Replacement plug-in relay - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85364900990
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-37-16-01
• eCl@ss 9.0: 27-37-16-01
• ETIM 8.0: EC001437
• ETIM 9.0: EC001437
• GTIN: 4045454560058
• Packaging type: box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 15 (1) pcs

Environmental Product Compliance

• CAS-No.: 80-05-7
• REACH Candidate List Substance: 4,4'-isopropylidenediphenol
• RoHS Compliance Status: Compliant,No Exemption
• SCIP notification number (Austria): a831fa41-902b-448d-8708-df84f5d7ce18
• SCIP notification number (Belgium): 8700ad89-07b6-4e62-be0e-a0a642011f1a
• SCIP notification number (Bulgaria): 0c34640b-59d7-482f-b5f8-63fb7d2ad751
• SCIP notification number (Czech Republic): b1cd5ba9-fa4d-4888-86e5-409c84102a41
• SCIP notification number (Denmark): fba882a1-da22-4d7b-8f65-d15634496562
• SCIP notification number (Finland): 8a1af4b8-6cdf-48ad-a410-4b270d3107ef
• SCIP notification number (France): bab64cf2-1fc8-4aba-92f8-b0d7f938c19d
• SCIP notification number (Germany): a0ec7c04-f8ed-456d-ac92-9c1237675c40
• SCIP notification number (Hungary): 68b35ee8-a788-4525-9f12-4e43283a3192
• SCIP notification number (Italy): 8d40aba2-1081-4917-8763-a461206eb294
• SCIP notification number (Netherlands): f84b3362-893e-4499-84e9-eb56e58e4e4d
• SCIP notification number (Poland): 7897a7aa-7620-47a5-97d9-66d501bd3341
• SCIP notification number (Romania): ef26a14d-9a95-4664-8471-8cb204157e03
• SCIP notification number (Sweden): 91af85f1-d12c-46f4-b43a-932a24d790a4

Environmental requirements

• Ambient temperature (operation at U_N): -25 … +40 °C
• Ambient temperature (storage): -25 … +70 °C
• Operating altitude (max.): 2000m
• Processing temperature: -25 … +50 °C
• Relative humidity: 5 … 75 % (no condensation permissible)
• Temperature range of connection cable: ≥ (T_ambient + 35 K)

Material data

• Color: gray
• Fire load: 0.346MJ
• Note (material data):
  Information on material specifications can be found here

• Weight: 30.6g

Mechanical data

• Mounting type: Pluggable module for receptacle terminal blocks

Physical data

• Depth from upper-edge of DIN-rail: 82.5 mm / 3.248 inches
• Height: 52 mm / 2.047 inches
• Note (dimensions): Depth including carrier terminal block
• Width: 15 mm / 0.591 inches

Safety and protection

• Dielectric strength (control/load circuit) (AC, 1 min): 4 kVrms
• Dielectric strength (open contact) (AC, 1 min): 1 kVrms
• Insulation type (between adjacent devices of the same type): Double insulation (safe isolation)
• Insulation type (control/load circuit): Reinforced insulation (safe isolation)
• Insulation type (to adjacent devices of different types): Basic insulation
• Overvoltage category: II
• Pollution degree: 2
• Protection type: IP20
• Rated impulse withstand voltage: 4kV
• Rated voltage: 300V

Standards and specifications

• Standards/specifications: EN 61010-2-201

Technical data

• Control circuit - Input voltage range: ±10 %
• Control circuit - Nominal input current at U_N: 4 mA
• Control circuit - Nominal input voltage U_N: 230 VAC
• Load circuit - Bounce time (typ.): 4ms
• Load circuit - Contact material (relay): AgNi 0.15
• Load circuit - Drop-out time (typ.): 6ms
• Load circuit - Electrical life (NO; resistive load; 23 °C): 100 x 10³ switching operations
• Load circuit - Limiting continuous current: 7 A
• Load circuit - Mechanical life: 30 x 10⁶ switching operations
• Load circuit - Number of changeover/switchover contacts: 1
• Load circuit - Pull-in time (typ.): 8ms
• Load circuit - Switching power (resistive) max.: AC 1750 VA
• Load circuit - Switching Voltage, Max.: 250 VAC
• Signaling - Status indicator: Red LED
