Wago - 286-316

Replacement plug-in relay with red LED - WAGO (286 series) - 2-poles (2P) - control voltage 198-242Vdc (220Vdc nom.; 0.9...1.1 x Uc) - 2C/O / DPDT (Double Pole Double Throw) contact - Electromechanical design - Rated current 7A (continuous) - with plug-in connections - Plug-in mounting - IP20 - material Silver-Nickel (AgNi 0.15) contacts - equivalent to 286316

Specifications

• Primary brand: WAGO
• Functions: Replacement plug-in relay
• Design: red LED|Electromechanical design
• Poles: 2-poles (2P)
• Temperature: Processing temperature -25°C...+50°C
• Rated current: 7A (continuous)
• Rated operating voltage (Ue): 250V
• Rated voltage (AC): 250Vac max. (switching voltage)
• Rated impulse voltage (Uimp): 4kV
• Connection type: plug-in connections
• Control Voltage (DC): 198-242Vdc (220Vdc nom.; 0.9...1.1 x Uc)
• Mounting mode: Plug-in
• Response time: (OFF=>ON / contacts closing) 18ms / 0.018s|(ON=>OFF / contacts opening) 3ms / 0.003s
• Contacts type: 2C/O / DPDT (Double Pole Double Throw) contact
• Dimensions: H82.5mm x W20mm x D52mm
• Material: Silver-Nickel (AgNi 0.15) contacts
• Ambient air temperature for operation: -25°C...+40°C
• Ambient air temperature for storage: -25°C...+70°C
• Humidity: 5-85% relative humidity (RH; non-condensing)
• Electrical durability (with load): 100 000operations
• Mechanical durability (at no load): 30 000 000operations
• eClass code: 27-37-16-01
• ETIM code: EC001437
• GTIN code: 4045454553630
• Customs Tariff Number: 85364900990
• Order code / Manufacturer SKU: 286-316
• Manufacturer product status: Commercialized
• Equivalent to: 286316
• EAN code: 4045454553630
• Compliant with standard(s): EN 60664-1|General approvals|- EAC - GZO Almaty Standart - TP TC 004/2011 - certificate EAC CoC 03078|RoHS compliant with exemption (7(a) / 7(c)-I / 7(c)-II)
• Location of origin: Germany
• Degree of pollution: 2
• Level 1 category: Automation components
• Level 2 category: Control components
• Level 3 category: Control relays
• Product title: Replacement plug-in relay - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85364900990
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-37-16-01
• eCl@ss 9.0: 27-37-16-01
• ETIM 8.0: EC001437
• ETIM 9.0: EC001437
• GTIN: 4045454553630
• Packaging type: box
• Product Group: 6 (INTERFACE ELECTRONIC)
• PU (SPU): 10 (1) pcs

Environmental Product Compliance

• CAS-No.: 7439-92-1|79-94-7
• REACH Candidate List Substance: 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol|Lead
• RoHS Compliance Status: Compliant,With Exemption
• RoHS Exemption: 7(a)|7(c)-I|7(c)-II
• SCIP notification number (Austria): caf48449-c7ee-41e9-95e9-9c7347f5a471
• SCIP notification number (Belgium): 19b3c68c-da4e-4fce-bbec-828212c1274e
• SCIP notification number (Bulgaria): 0ad6742e-07e0-4988-b877-53302f4f6641
• SCIP notification number (Czech Republic): 41b82857-80e3-4e9c-b1b0-020df7badcbd
• SCIP notification number (Denmark): 1dc88fbd-b839-4a5f-9cdf-00658da2f389
• SCIP notification number (Finland): 3257e224-f588-41ad-a739-b35461f564e7
• SCIP notification number (France): bb67425c-5805-4d57-9526-76cc55e71290
• SCIP notification number (Germany): 9cce2dc6-4c1c-4f99-8137-9b75efeb9adb
• SCIP notification number (Hungary): b175298b-1f3e-423f-ba1a-7d9379d76843
• SCIP notification number (Italy): a439bf26-59b6-4da5-9464-6643e602a2d7
• SCIP notification number (Netherlands): 5f468ac6-4287-4397-b076-c8a390ce95c3
• SCIP notification number (Poland): c5ca149a-06a8-4602-bd0a-45d0a40344c6
• SCIP notification number (Romania): 984a7288-1d9a-4d9b-8752-7dabce81f526
• SCIP notification number (Sweden): f005a10c-679a-481f-a25c-9ed51aa27736

Environmental requirements

• Ambient temperature (operation at U_N): -25 … +40 °C
• Ambient temperature (storage): -25 … +70 °C
• Operating altitude (max.): 2000m
• Processing temperature: -25 … +50 °C
• Relative humidity: 5 … 85 % (no condensation permissible)

Material data

• Color: gray
• Fire load: 0.414MJ
• Note (material data):
  Information on material specifications can be found here

• Weight: 39.9g

Mechanical data

• Mounting type: Pluggable module for receptacle terminal blocks

Physical data

• Depth from upper-edge of DIN-rail: 82.5 mm / 3.248 inches
• Height: 52 mm / 2.047 inches
• Note (dimensions): Depth including carrier terminal block
• Width: 20 mm / 0.787 inches

Safety and protection

• Dielectric strength (control/load circuit) (AC, 1 min): 2 kVrms
• Dielectric strength (load/load circuit) (AC, 1 min): 1.5 kVrms
• Dielectric strength (open contact) (AC, 1 min): 1 kVrms
• Pollution degree: 2
• Protection type: IP20
• Rated impulse withstand voltage: 4kV
• Rated voltage: 250V

Standards and specifications

• Standards/specifications: EN 60664-1

Technical data

• Control circuit - Input voltage range: ±10 %
• Control circuit - Nominal input current at U_N: 5 mA
• Control circuit - Nominal input voltage U_N: 220 VDC
• Load circuit - Bounce time (typ.): 2ms
• Load circuit - Contact material (relay): AgNi 0.15
• Load circuit - Drop-out time (typ.): 3ms
• Load circuit - Electrical life (NO; resistive load; 23 °C): 100 x 10³ switching operations
• Load circuit - Limiting continuous current: 7 A
• Load circuit - Mechanical life: 30 x 10⁶ switching operations
• Load circuit - Number of changeover/switchover contacts: 2
• Load circuit - Pull-in time (typ.): 18ms
• Load circuit - Switching power (resistive) max.: AC 1750 VA
• Load circuit - Switching Voltage, Max.: 250 VAC
• Signaling - Status indicator: Red LED
