Replacement plug-in relay with red LED - WAGO (286 series) - single-pole / 1-pole (1P) - control voltage 77-137.5Vdc (110Vdc nom.; 0.7...1.25 x Uc) - 1C/O / SPDT (Single Pole Double Throw) contact - Electromechanical design - Rated current 3A (continuous) - with plug-in connections - Plug-in mounting - IP20 - material Silver-Nickel (AgNi 0.15) contacts - equivalent to 286307004000

Specifications

  • Primary brand: WAGO
  • Functions: Replacement plug-in relay
  • Design: red LED|Electromechanical design
  • Poles: single-pole / 1-pole (1P)
  • Temperature: Processing temperature -25°C...+50°C
  • Rated current: 3A (continuous)
  • Rated operating voltage (Ue): 300V
  • Rated voltage (AC): 250Vac max. (switching voltage)
  • Connection type: plug-in connections
  • Control Voltage (DC): 77-137.5Vdc (110Vdc nom.; 0.7...1.25 x Uc)
  • Mounting mode: Plug-in
  • Response time: (OFF=>ON / contacts closing) 8ms / 0.008s|(ON=>OFF / contacts opening) 6ms / 0.006s
  • Contacts type: 1C/O / SPDT (Single Pole Double Throw) contact
  • Dimensions: H82.5mm x W15mm x D52mm
  • Material: Silver-Nickel (AgNi 0.15) contacts
  • Ambient air temperature for operation: -25°C...+70°C
  • Ambient air temperature for storage: -25°C...+70°C
  • Humidity: 5-85% relative humidity (RH; non-condensing)
  • eClass code: 27-37-16-01
  • GTIN code: 4045454709105
  • Customs Tariff Number: 85364900990
  • ETIM code: EC001437
  • Order code / Manufacturer SKU: 286-307/004-000
  • Manufacturer product status: Commercialized
  • Equivalent to: 286307004000
  • EAN code: 4045454709105
  • Compliant with standard(s): Safety and protection|- Overvoltage category -- II|EN 61010-2-201|General approvals|- EAC - GZO Almaty Standart - TP TC 004/2011 - certificate EAC CoC 03078|- EAC - GZO Almaty Standart - TP TC 020/2011 - certificate EAC CoC 03081|Declarations of conformity and manufacturer's declarations|- EU-Declaration of Conformity - WAGO GmbH & Co. KG|RoHS compliant with exemption (7(a) / 7(c)-I / 7(c)-II)
  • Location of origin: Germany
  • Degree of pollution: 2
  • Level 1 category: Automation components
  • Level 2 category: Control components
  • Level 3 category: Control relays
  • Product title: Replacement plug-in relay - WAGO

Commercial data

  • Country of origin: DE
  • Customs tariff number: 85364900990
  • ECCN: NO US CLASSIFICATION
  • eCl@ss 10.0: 27-37-16-01
  • eCl@ss 9.0: 27-37-16-01
  • ETIM 8.0: EC001437
  • ETIM 9.0: EC001437
  • GTIN: 4045454709105
  • Packaging type: box
  • Product Group: 6 (INTERFACE ELECTRONIC)
  • PU (SPU): 15 (1) pcs

Environmental Product Compliance

  • CAS-No.: 1303-86-2|7439-92-1|79-94-7
  • REACH Candidate List Substance: 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol|Diboron trioxide|Lead
  • RoHS Compliance Status: Compliant,With Exemption
  • RoHS Exemption: 7(a)|7(c)-I|7(c)-II
  • SCIP notification number (Austria): 81828017-49df-4293-a656-88ad43efb054
  • SCIP notification number (Belgium): 5ddc4fe6-0673-499a-8e00-c8dfe3e61a8d
  • SCIP notification number (Bulgaria): 08b6913c-7e63-49aa-868c-5905e8b4cd05
  • SCIP notification number (Czech Republic): 6fc70c82-1fab-4a89-8148-b9a659039b3a
  • SCIP notification number (Denmark): af3d9c6f-763c-4fb5-8461-e5edef4dae6d
  • SCIP notification number (Finland): 910b84da-0a64-4266-a73b-82f0562b16e7
  • SCIP notification number (France): 8e409d76-c604-4f79-8e66-0310246cb279
  • SCIP notification number (Germany): 006dadc3-90a1-45d5-b130-4c5dc5632ff3
  • SCIP notification number (Hungary): 7c1acc02-2e72-4027-bf12-0cafff02106e
  • SCIP notification number (Italy): e333515a-0f47-4cca-bb4c-785059621f90
  • SCIP notification number (Netherlands): 0c5e03ed-27b1-489b-9876-f99ccce5af3c
  • SCIP notification number (Poland): 6df00da0-9c65-403f-82b3-92d439f1046f
  • SCIP notification number (Romania): cb548765-5811-44dc-9de0-25cb0a5d1a0e
  • SCIP notification number (Sweden): 3418933c-d55f-4ac5-b907-4b47107f3f03

Environmental requirements

  • Ambient temperature (operation at UN): -25 … +70 °C
  • Ambient temperature (storage): -25 … +70 °C
  • Operating altitude (max.): 2000m
  • Processing temperature: -25 … +50 °C
  • Relative humidity: 5 … 85 % (no condensation permissible)

Material data

Mechanical data

  • Mounting type: Pluggable module for receptacle terminal blocks

Physical data

  • Depth from upper-edge of DIN-rail: 82.5 mm / 3.248 inches
  • Height: 52 mm / 2.047 inches
  • Note (dimensions): Depth including carrier terminal block
  • Width: 15 mm / 0.591 inches

Safety and protection

  • Dielectric strength (control/load circuit) (AC, 1 min): 3 kVrms
  • Dielectric strength (open contact) (AC, 1 min): 1 kVrms
  • Insulation type (adjacent devices): Reinforced insulation (safe isolation)
  • Insulation type (control/load circuit): Reinforced insulation (safe isolation)
  • Overvoltage category: II
  • Pollution degree: 2
  • Protection type: IP20
  • Rated voltage: 300V

Standards and specifications

  • Standards/specifications: EN 61010-2-201

Technical data

  • Control circuit - Input voltage range: -30 … +25 %
  • Control circuit - Nominal input current at UN: 4 mA
  • Control circuit - Nominal input voltage UN: 110 VDC
  • Load circuit - Bounce time (typ.): 4ms
  • Load circuit - Contact material (relay): AgNi 0.15
  • Load circuit - Drop-out time (typ.): 6ms
  • Load circuit - Limiting continuous current: 3 A
  • Load circuit - Number of changeover/switchover contacts: 1
  • Load circuit - Pull-in time (typ.): 8ms
  • Load circuit - Switching power (resistive) max.: AC 750 VA
  • Load circuit - Switching Voltage, Max.: 250 VAC
  • Signaling - Status indicator: Red LED
