Wago - 272-303

WAGO component - equivalent to 272303

Specifications

• Primary brand: WAGO
• GTIN code: 4044918397155
• Order code / Manufacturer SKU: 272-303
• Manufacturer product status: Commercialized
• Equivalent to: 272303
• EAN code: 4044918397155
• Manufacturer description: Power supply connector; push-button on both sides; without snap-in mounting feet; without ground contact; 3-pole; 2.5mm2; white
• Manufacturer product specifications: Electrical data - Ratings per IEC/EN - Ratings per -- IEC/EN 60664-1|Electrical data - Ratings per IEC/EN - Rated voltage (III/2) -- 400V|Electrical data - Ratings per IEC/EN - Rated surge voltage (III/2) -- 4kV|Electrical data - Ratings per IEC/EN - Rated current -- 18A|Electrical data - Ratings per IEC/EN - Legend (ratings) -- (III / 2) Overvoltage category III / Pollution degree 2|Connection data - Clamping units -- 12|Connection data - Total number of potentials -- 3|Connection data - Number of connection types -- 1|Connection data - Connection 1 - Connection technology -- PUSH WIRE|Connection data - Connection 1 - Solid conductor -- 0.5...1.5mm2 / 20...16 AWG|Connection data - Connection 1 - Strip length -- 8...9mm / 0.31...0.35"|Connection data - Connection 1 - Pole number -- 3|Connection data - Connection 2 - Solid conductor 2 -- 0.5...2.5mm2 / 20...14 AWG|Physical data - Width -- 28.5mm / 1.122"|Physical data - Height -- 19mm / 0.748"|Physical data - Depth -- 24.5mm / 0.965"|Material data - Color -- white|Material data - Material group -- I|Material data - Insulation material (main housing) -- Polyamide (PA66)|Material data - Flammability class per UL94 -- V0|Material data - Fire load -- 0.226MJ|Material data - Weight -- 9.4g|Commercial data - Product Group -- 8 (Misc. Chassis Mount Blocks)|Commercial data - eClass 10.0 -- 27-14-11-04|Commercial data - eClass 9.0 -- 27-14-11-04|Commercial data - ETIM 9.0 -- EC000446|Commercial data - ETIM 8.0 -- EC000446|Commercial data - ECCN -- NO DATA|Commercial data - PU (SPU) -- 500 pcs|Commercial data - Packaging type -- bag|Commercial data - Country of origin -- PL|Commercial data - GTIN -- 4044918397155|Commercial data - Customs tariff number -- 85369010000|Environmental Product Compliance - RoHS Compliance Status -- Compliant;No Exemption
• Location of origin: Poland
• Level 1 category: Cabling systems
• Level 2 category: Connectors & Inserts

Commercial data

• Country of origin: PL
• Customs tariff number: 85369010000
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-14-11-04
• eCl@ss 9.0: 27-14-11-04
• ETIM 8.0: EC000446
• ETIM 9.0: EC000446
• GTIN: 4044918397155
• Packaging type: bag
• Product Group: 8 (Misc. Chassis Mount Blocks)
• PU (SPU): 500 pcs

Connection data

• Clamping units: 12
• Connection 1 - Connection technology: PUSH WIRE^®
• Connection 1 - Pole number: 3
• Connection 1 - Solid conductor: 0.5 … 1.5 mm² / 20 … 16 AWG
• Connection 1 - Strip length: 8 … 9 mm / 0.31 … 0.35 inches
• Connection 2 - Solid conductor: 0.5 … 2.5 mm² / 20 … 14 AWG
• Number of connection types: 1
• Total number of potentials: 3

Electrical data

• Ratings per IEC/EN - Legend (ratings): (III / 2) ≙ Overvoltage category III / Pollution degree 2
• Ratings per IEC/EN - Rated current: 18A
• Ratings per IEC/EN - Rated impulse withstand voltage (III/2): 4kV
• Ratings per IEC/EN - Rated voltage (III/2): 400V
• Ratings per IEC/EN - Ratings per: IEC/EN 60664-1

Environmental Product Compliance

• RoHS Compliance Status: Compliant,No Exemption

Material data

• Color: white
• Fire load: 0.226MJ
• Flammability class per UL94: V0
• Insulation material (main housing): Polyamide (PA66)
• Material group: I
• Note (material data):
  Information on material specifications can be found here

• Weight: 9.4g

Physical data

• Depth: 24.5 mm / 0.965 inches
• Height: 19 mm / 0.748 inches
• Width: 28.5 mm / 1.122 inches
