Wago - 262-256

Feed-through/thru terminal strip with 1-deck/level + snap-in mounting feet - WAGO (262 series) - Gray - 6 feed-through poles (6P) / 24-wires (12 clamps + 12 clamps) (12+12) - for 0.08mm2...4mm2 / for #28AWG...#12AWG - Rated current 32A - with CAGE CLAMP spring connections - Mounts on DIN rail or surface via accessory snap-in foot mounting - equivalent to 262256

Specifications

• Primary brand: WAGO
• Functions: Feed-through/thru terminal strip
• Design: 1-deck/level|snap-in mounting feet
• Poles: 6 feed-through poles (6P)
• Rated current: (IEC) 32A|(UL) 20A
• Color: Gray
• Connection capacity: 24-wires (12 clamps + 12 clamps) (12+12)
• Rated operating voltage (Ue): (IEC) 630V|(UL) 300V|(CSA) 300V
• Rated impulse voltage (Uimp): (IEC) 8kV
• Connection type: CAGE CLAMP spring connections
• Cross-section: for 0.08mm2...4mm2 fine stranded or solid conductors|for #28AWG...#12AWG fine stranded or solid conductors
• Mounting mode: Mounts on DIN rail or surface via accessory snap-in foot
• Dimensions: H33.5mm x W75mm x D27.5mm
• Material: Polyamide (PA) 66|Halogen-free materials
• eClass code: 27-14-11-06
• GTIN code: 4044918641692
• Customs Tariff Number: 85369010000
• ETIM code: EC001284
• Order code / Manufacturer SKU: 262-256
• Manufacturer product status: Commercialized
• Equivalent to: 262256
• EAN code: 4044918641692
• Compliant with standard(s): General approvals|- CCA - DEKRA Certification B.V. - EN 60998 - certificate NTR NL 7661|- CCC - CQC - GB/T 13140.1 - certificate CQC04003009928|- CQC - CHINA QUALITY CERT. CENTRE - GB/T 13140.3 - certificate CQC04003009928|- CSA - DEKRA Certification B.V. - C22.2 - certificate 70010891|- KEMA/KEUR - DEKRA Certification B.V. - EN 60998 - certificate 71-102644|- UR - Underwriters Laboratories Inc. - UL 1059 - certificate E45172|Declarations of conformity and manufacturer's declarations|- EU-Declaration of Conformity - WAGO GmbH & Co. KG|- UK-Declaration of Conformity - WAGO GmbH & Co. KG|Approvals for marine applications|- ABS - American Bureau of Shipping - certificate 19-HG1869868-PDA|- BV - Bureau Veritas S.A. - EN 60947 - certificate 07436/F0 BV|- DNV GL - Det Norske Veritas Germanischer Lloyd - certificate TAE00001V2|- LR - Lloyds Register - IEC 60998 - certificate LR22173030TA|RoHS compliant|material group I|V-0 flammability rating
• Location of origin: Germany
• Level 1 category: Electrical components
• Level 2 category: Terminal blocks
• Product title: Feed-through/thru terminal strip - 1-deck/level - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85369010000
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-14-11-06
• eCl@ss 9.0: 27-14-11-06
• ETIM 8.0: EC001284
• ETIM 9.0: EC001284
• GTIN: 4044918641692
• Packaging type: box
• PU (SPU): 50 pcs

Connection data

• Clamping units: 24
• Connection 1 - Actuation type: Operating tool
• Connection 1 - Connectable conductor materials: Copper
• Connection 1 - Connection technology: CAGE CLAMP^®
• Connection 1 - Fine-stranded conductor: 0.08 … 4 mm² / 28 … 12 AWG
• Connection 1 - Pole number: 6
• Connection 1 - Solid conductor: 0.08 … 4 mm² / 28 … 12 AWG
• Connection 1 - Strip length: 9 … 10 mm / 0.35 … 0.39 inches
• Connection 1 - Wiring direction: Side-entry wiring
• Number of levels: 1
• Total number of potentials: 6

Electrical data

• Ratings per CSA - Approvals per: CSA 22.2 No 158
• Ratings per CSA - Rated current CSA (Use Group B): 5A
• Ratings per CSA - Rated current CSA (Use Group C): 25A
• Ratings per CSA - Rated current CSA (Use Group D): 5A
• Ratings per CSA - Rated voltage CSA (Use Group B): 600V
• Ratings per CSA - Rated voltage CSA (Use Group C): 300V
• Ratings per CSA - Rated voltage CSA (Use Group D): 600V
• Ratings per IEC/EN - Legend (ratings): (III / 3) ≙ Overvoltage category III / Pollution degree 3
• Ratings per IEC/EN - Nominal voltage (III/3): 630V
• Ratings per IEC/EN - Rated current: 32A
• Ratings per IEC/EN - Rated impulse withstand voltage (III / 3): 8kV
• Ratings per UL - Approvals per: UL 1059
• Ratings per UL - Rated current UL (Use Group B): 20A
• Ratings per UL - Rated current UL (Use Group C): 20A
• Ratings per UL - Rated current UL (Use Group D): 10A
• Ratings per UL - Rated voltage UL (Use Group B): 300V
• Ratings per UL - Rated voltage UL (Use Group C): 300V
• Ratings per UL - Rated voltage UL (Use Group D): 300V

Environmental Product Compliance

• RoHS Compliance Status: Compliant,No Exemption

Material data

• Color: gray
• Fire load: 0.717MJ
• Flammability class per UL94: V0
• Halogen-free: Yes
• Insulation material (main housing): Polyamide (PA66)
• Material group: I
• Note (material data):
  Information on material specifications can be found here

• Weight: 43.2g

Mechanical data

• Design: horizontal type
• Marking level: Side marking
• Mounting type: Snap-in foot

Physical data

• Depth: 27.5 mm / 1.083 inches
• Height: 33.5 mm / 1.319 inches
• Height from the surface: 23.1 mm / 0.909 inches
• Module width: 12 mm / 0.472 inches
• Width: 75 mm / 2.953 inches
