Wago - 216-547

Compression/crimp twin wires / cables insulated end sleeve / ferrule - WAGO (216 series) - for 2 x 6mm2 / for 2 x #10AWG - Rated current 63A - Yellow color - 12mm sleeve length - equivalent to 216547

Specifications

• Primary brand: WAGO
• Functions: Compression/crimp twin wires / cables insulated end sleeve / ferrule
• Rated current: 63A
• Color: Yellow
• Cross-section: for 2 x 6mm2 conductors|for 2 x #10AWG conductors
• Length: 12mm sleeve
• Dimensions: 23mm overall length (L)|11.4mm insulating collar inner diameter (D)|6.2mm insulating collar inner diameter (D1)|4.7mm ferrule diameter (D2)|requires 12mm / 0.47" cable stripping length
• Technical compatibility with: 811 series
• eClass code: 27-40-02-01
• ETIM code: EC000005
• GTIN code: 4055143583367
• Customs Tariff Number: 85369010000
• Order code / Manufacturer SKU: 216-547
• Manufacturer product status: Commercialized
• Equivalent to: 216547
• EAN code: 4055143583367
• Compliant with standard(s): RoHS compliant
• Location of origin: Germany
• Level 1 category: Cabling systems
• Level 2 category: Connectors & Inserts
• Level 3 category: Cable ferrules
• Product title: Compression/crimp twin wires / cables insulated end sleeve / ferrule - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85369010000
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-40-02-01
• eCl@ss 9.0: 27-40-02-01
• ETIM 8.0: EC000005
• ETIM 9.0: EC000005
• GTIN: 4055143583367
• Packaging type: box
• PU (SPU): 100 pcs

Connection data

• Cross-section AWG: 2 x 10AWG
• Cross-section metric: 6mm²
• Strip length: 13.5 … 14.5 mm / 0.53 … 0.57 inches

Environmental Product Compliance

• RoHS Compliance Status: Compliant,No Exemption

Material data

• Color: yellow
• Weight: 0.6g

Physical data

• Crimp length (length of sleeve): 12mm
• Diameter crimp sleeve inside: 4.7mm
• Inner dimension plastic collar large: 11.4mm
• Inner dimension plastic collar small: 6.2mm
• Total length: 23mm
• Wall thickness crimp sleeve: 0.2mm
• Wall thickness plastic collar: 0.5mm
