Wago - 216-1543

Compression/crimp twin wires / cables insulated end sleeve / ferrule - WAGO (216 series) - for 2 x 1.5mm2 / for 2 x #16AWG - Black color - 12mm sleeve length - equivalent to 2161543

Specifications

• Primary brand: WAGO
• Functions: Compression/crimp twin wires / cables insulated end sleeve / ferrule
• Color: Black
• Cross-section: for 2 x 1.5mm2 conductors|for 2 x #16AWG conductors
• Length: 12mm sleeve
• Dimensions: 20mm overall length (L)|6.5mm insulating collar inner diameter (D)|3.6mm insulating collar inner diameter (D1)|2.35mm ferrule diameter (D2)|requires 13.5mm...14.5mm / 0.53"...0.57" cable stripping length
• ETIM code: EC000005
• Customs Tariff Number: 85369010000
• GTIN code: 4055143642811
• Order code / Manufacturer SKU: 216-1543
• Manufacturer product status: Commercialized
• Equivalent to: 2161543
• Compliant with standard(s): RoHS compliant
• Location of origin: Germany
• Level 1 category: Cabling systems
• Level 2 category: Connectors & Inserts
• Level 3 category: Cable ferrules
• Product title: Compression/crimp twin wires / cables insulated end sleeve / ferrule - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85369010000
• ECCN: NO US CLASSIFICATION
• ETIM 8.0: EC000005
• ETIM 9.0: EC000005
• GTIN: 4055143642811
• Packaging type: bag
• PU (SPU): 1000 pcs

Connection data

• Cross-section AWG: 2 x 16AWG
• Cross-section metric: 1.5mm²
• Strip length: 13.5 … 14.5 mm / 0.53 … 0.57 inches

Environmental Product Compliance

• RoHS Compliance Status: Compliant,No Exemption

Material data

• Color: black
• Weight: 0.2g

Physical data

• Crimp length (length of sleeve): 12mm
• Diameter crimp sleeve inside: 2.35mm
• Inner dimension plastic collar large: 6.5mm
• Inner dimension plastic collar small: 3.6mm
• Total length: 20mm
• Wall thickness crimp sleeve: 0.15mm
• Wall thickness plastic collar: 0.3mm
