Wago - 211-504

Continuous heat-shrinkable printable sleeve - WAGO (211 series) - White color - Slide-on directly onto conductor mounting - Diameter 9.5mm - contains 15m per roll - compatible with for 10mm2...16mm2 conductors - equivalent to 211504

Specifications

• Primary brand: WAGO
• Functions: Continuous heat-shrinkable printable sleeve
• Color: White
• Diameter: 9.5mm
• Mounting mode: Slide-on directly onto conductor
• Material: Halogen-free materials
• Ambient air temperature for operation: -55°C...+125°C
• Humidity: 45-55% relative humidity (RH)
• Contents: 15m per roll
• Technical compatibility with: for 10mm2...16mm2 conductors
• ETIM code: EC001530
• GTIN code: 4055143370295
• Customs Tariff Number: 39173200900
• eClass code: 27-40-04-01
• Order code / Manufacturer SKU: 211-504
• Manufacturer product status: Commercialized
• Equivalent to: 211504
• Compliant with standard(s): RoHS compliant
• Location of origin: Denmark
• Level 1 category: Cabling systems
• Level 2 category: Labelling
• Level 3 category: Wire and cable labels
• Product title: Continuous heat-shrinkable printable sleeve - WAGO

Commercial data

• Country of origin: DK
• Customs tariff number: 39173200900
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-40-04-01
• eCl@ss 9.0: 27-40-04-01
• ETIM 8.0: EC001530
• ETIM 9.0: EC001530
• GTIN: 4055143370295
• Packaging type: box
• PU (SPU): 1 pcs

Environmental Product Compliance

• RoHS Compliance Status: Compliant,No Exemption

Environmental requirements

• Ambient temperature (operation): -55 … +125 °C
• Ambient temperature (storage): +10 … +25 °C
• Relative humidity: 45 … 55 %

Material data

• Adhesive information: without adhesive
• Color: white
• Halogen-free: Yes
• Material: Polyolefin
• UV resistance: EN 60068-2-5:2010 Procedure B
• Weight: 328.3g

Mechanical data

• Mounting type: Sliding on conductor
• Shrink rate: 2:1
• Smear resistance: in conjunction with 258-5005 Ink Ribbon

Physical data

• Depth: 0.185 mm

Technical data

• Delivery form: Roll
• Delivery form configuration: 15 m/roll
• Marking method: Thermal transfer
• Printing device: Smart Printer (Thermal Transfer Printer)
• Suitable: for wire cross-section 10 … 16 mm²
