Leuze 50136248 HT3C.XL/2N-M8 Diffuse sensor with background suppression
$236.43
Sale price
$236.43
Regular price
Skip to product information
Application: Detection of objects with openings, Detection of highly transparent bottles, Detection of transparent films
Special version: Extra long light spot (XL)
Operating range limit, white 90%: 0.005 ... 0.1 m
Light source: LED, Red
Supply voltage: 10 ... 30 V, DC
Digital switching outputs: 2 Piece(s)
Switching output 1: Transistor, NPN, Light switching
Switching output 2: Transistor, NPN, Dark switching
Switching frequency: 1,000 Hz
Connection: Connector, M8, Metal, 4 -pin
Design, housing: Cubic
Dimensions: 11.4 mm x 34.2 mm x 18.3 mm
Housing material: Plastic
Operational controls: Multiturn potentiometer
Ambient temperature, operation: -40 ... 60 °C
Degree of protection: IP 69K, IP 67
Leuze 50136248 HT3C.XL/2N-M8 Diffuse sensor with background suppression
$236.43
Sale price
$236.43
Regular price
Special version: Extra long light spot (XL)
Operating range limit, white 90%: 0.005 ... 0.1 m
Light source: LED, Red
Supply voltage: 10 ... 30 V, DC
Digital switching outputs: 2 Piece(s)
Switching output 1: Transistor, NPN, Light switching
Switching output 2: Transistor, NPN, Dark switching
Switching frequency: 1,000 Hz
Connection: Connector, M8, Metal, 4 -pin
Design, housing: Cubic
Dimensions: 11.4 mm x 34.2 mm x 18.3 mm
Housing material: Plastic
Operational controls: Multiturn potentiometer
Ambient temperature, operation: -40 ... 60 °C
Degree of protection: IP 69K, IP 67
