Leuze 50113737 AMS 384i 40 H Optical distance sensor
$6,280.96
Sale price
$6,280.96
Regular price
Skip to product information
Pre-mounted with: Mounting plate
Special version: Heating
Light source: Laser, Red
Protection class: 2
Measurement range: 200 ... 40,000 mm
Absolute measurement accuracy: 2 mm
Reproducibility (3 sigma): 0.9 mm
Max. traverse rate: 10 m/s
Supply voltage: 18 ... 30 V, DC
Interface: Interbus-S
Connection: Connector, M12, 5 -pin
Dimensions: 84 mm x 166.5 mm x 159 mm
Housing material: Metal
Display: LC Display, LED
Ambient temperature, operation: -30 ... 50 °C
Degree of protection: IP 65
