Leuze 50113726 AMS 358i 120 Optical distance sensor
$6,924.96
Sale price
$6,924.96
Regular price
Skip to product information
Pre-mounted with: Mounting plate
Light source: Laser, Red
Protection class: 2
Measurement range: 200 ... 120,000 mm
Absolute measurement accuracy: 2 mm
Reproducibility (3 sigma): 1.5 mm
Max. traverse rate: 10 m/s
Supply voltage: 18 ... 30 V, DC
Interface: EtherNet IP
Connection: Connector, M12, 4 -pin
Dimensions: 84 mm x 166.5 mm x 159 mm
Housing material: Metal
Display: LC Display, LED
Ambient temperature, operation: -5 ... 50 °C
Degree of protection: IP 65
